Item #	Item Name	Body Length	Minimum Grip Range	Maximum Grip Range	Nominal Shear Force

L48090P	N/A Orlock™ 4.8 Millimeter (mm) Diameter and 9.0 Millimeter (mm) Body Length Steel Protruding Head Rivet	N/A 9.0 mm0.354 in	N/A 1.5 mm0.059 in	N/A 3.5 mm0.138 in	N/A 460 kgf1012 lbf
L48115P	N/A Orlock™ 4.8 Millimeter (mm) Diameter and 11.5 Millimeter (mm) Body Length Steel Protruding Head Rivet	N/A 11.5 mm0.453 in	N/A 3.5 mm0.138 in	N/A 6.0 mm0.236 in	N/A 610 kgf1342 lbf
L48140P	N/A Orlock™ 4.8 Millimeter (mm) Diameter and 14.9 Millimeter (mm) Body Length Steel Protruding Head Rivet	N/A 14.0 mm0.551 in	N/A 6.0 mm0.236 in	N/A 8.5 mm0.335 in	N/A 610 kgf1342 lbf
L48165P	N/A Orlock™ 4.8 Millimeter (mm) Diameter and 16.5 Millimeter (mm) Body Length Steel Protruding Head Rivet	N/A 16.5 mm0.650 in	N/A 8.5 mm0.335 in	N/A 11.0 mm0.433 in	N/A 640 kgf1408 lbf
L48190P	N/A Orlock™ 4.8 Millimeter (mm) Diameter and 19.0 Millimeter (mm) Body Length Steel Protruding Head Rivet	N/A 19.0 mm0.748 in	N/A 11.0 mm0.433 in	N/A 13.5 mm0.531 in	N/A 640 kgf1408 lbf
L64090P	N/A Orlock™ 6.4 Millimeter (mm) Diameter and 9.0 Millimeter (mm) Body Length Steel Protruding Head Rivet	N/A 9.0 mm0.354 in	N/A 1.5 mm0.059 in	N/A 3.5 mm0.138 in	N/A 700 kgf1540 lbf
L64105P	N/A Orlock™ 6.4 Millimeter (mm) Diameter and 10.5 Millimeter (mm) Body Length Steel Protruding Head Rivet	N/A 10.5 mm0.413 in	N/A 2.8 mm0.110 in	N/A 4.8 mm0.189 in	N/A 940 kgf2068 lbf
L64111P	N/A Orlock™ 6.4 Millimeter (mm) Diameter and 11.1 Millimeter (mm) Body Length Steel Protruding Head Rivet	N/A 11.1 mm0.437 in	N/A 3.4 mm0.134 in	N/A 5.4 mm0.213 in	N/A 940 kgf2068 lbf
L64125P	N/A Orlock™ 6.4 Millimeter (mm) Diameter and 12.5 Millimeter (mm) Body Length Steel Protruding Head Rivet	N/A 12.5 mm0.492 in	N/A 4.8 mm0.189 in	N/A 6.8 mm0.268 in	N/A 1040 kgf2288 lbf
L64145P	N/A Orlock™ 6.4 Millimeter (mm) Diameter and 14.5 Millimeter (mm) Body Length Steel Protruding Head Rivet	N/A 14.5 mm0.571 in	N/A 6.8 mm0.268 in	N/A 8.8 mm0.346 in	N/A 1140 kgf2508 lbf
L64165P	N/A Orlock™ 6.4 Millimeter (mm) Diameter and 16.5 Millimeter (mm) Body Length Steel Protruding Head Rivet	N/A 16.5 mm0.650 in	N/A 8.8 mm0.346 in	N/A 10.8 mm0.425 in	N/A 1140 kgf2508 lbf
L64185P	N/A Orlock™ 6.4 Millimeter (mm) Diameter and 18.5 Millimeter (mm) Body Length Steel Protruding Head Rivet	N/A 18.5 mm0.728 in	N/A 10.8 mm0.425 in	N/A 12.8 mm0.504 in	N/A 1140 kgf2508 lbf
L64205P	N/A Orlock™ 6.4 Millimeter (mm) Diameter and 20.5 Millimeter (mm) Body Length Steel Protruding Head Rivet	N/A 20.5 mm0.807 in	N/A 12.8 mm0.504 in	N/A 14.8 mm0.583 in	N/A 1140 kgf2508 lbf
L64225P	N/A Orlock™ 6.4 Millimeter (mm) Diameter and 22.5 Millimeter (mm) Body Length Steel Protruding Head Rivet	N/A 22.5 mm0.886 in	N/A 14.8 mm0.583 in	N/A 16.8 mm0.661 in	N/A 1140 kgf2508 lbf
L64245P	N/A Orlock™ 6.4 Millimeter (mm) Diameter and 24.5 Millimeter (mm) Body Length Steel Protruding Head Rivet	N/A 24.5 mm0.965 in	N/A 16.8 mm0.661 in	N/A 18.8 mm0.740 in	N/A 1140 kgf2508 lbf
L64265P	N/A Orlock™ 6.4 Millimeter (mm) Diameter and 26.5 Millimeter (mm) Body Length Steel Protruding Head Rivet	N/A 26.5 mm1.043 in	N/A 18.8 mm0.740 in	N/A 20.8 mm0.819 in	N/A 1140 kgf2508 lbf
L64285P	N/A Orlock™ 6.4 Millimeter (mm) Diameter and 28.5 Millimeter (mm) Body Length Steel Protruding Head Rivet	N/A 28.5 mm1.122 in	N/A 20.8 mm0.819 in	N/A 22.8 mm0.898 in	N/A 1140 kgf2508 lbf
L64305P	N/A Orlock™ 6.4 Millimeter (mm) Diameter and 30.5 Millimeter (mm) Body Length Steel Protruding Head Rivet	N/A 30.5 mm1.201 in	N/A 22.8 mm22.8 in	N/A 24.8 mm0.976 in	N/A 1140 kgf2508 lbf
L64325P	N/A Orlock™ 6.4 Millimeter (mm) Diameter and 32.5 Millimeter (mm) Body Length Steel Protruding Head Rivet	N/A 32.5 mm1.280 in	N/A 24.8 mm24.8 in	N/A 26.8 mm1.055 in	N/A 1140 kgf2508 lbf
L64355P	N/A Orlock™ 6.4 Millimeter (mm) Diameter and 35.5 Millimeter (mm) Body Length Steel Protruding Head Rivet	N/A 35.5 mm1.398 in	N/A 25.8 mm25.8 in	N/A 28.8 mm1.134 in	N/A 1140 kgf2508 lbf
L64375P	N/A Orlock™ 6.4 Millimeter (mm) Diameter and 37.5 Millimeter (mm) Body Length Steel Protruding Head Rivet	N/A 37.5 mm1.476 in	N/A 27.8 mm27.8 in	N/A 30.8 mm1.213 in	N/A 1140 kgf2508 lbf
L64395P	N/A Orlock™ 6.4 Millimeter (mm) Diameter and 39.5 Millimeter (mm) Body Length Steel Protruding Head Rivet	N/A 39.5 mm1.555 in	N/A 29.8 mm29.8 in	N/A 32.8 mm1.291 in	N/A 1140 kgf2508 lbf
L78135P	N/A Orlock™ 7.8 Millimeter (mm) Diameter and 13.5 Millimeter (mm) Body Length Steel Protruding Head Rivet	N/A 13.5 mm0.531 in	N/A 4.0 mm4.0 in	N/A 7.0 mm0.276 in	N/A 1410 kgf3102 lbf
L78165P	N/A Orlock™ 7.8 Millimeter (mm) Diameter and 16.5 Millimeter (mm) Body Length Steel Protruding Head Rivet	N/A 16.5 mm0.650 in	N/A 7.0 mm7.0 in	N/A 10.0 mm0.394 in	N/A 1600 kgf3520 lbf
L78195P	N/A Orlock™ 7.8 Millimeter (mm) Diameter and 19.5 Millimeter (mm) Body Length Steel Protruding Head Rivet	N/A 19.5 mm0.768 in	N/A 10.0 mm10.0 in	N/A 13.0 mm0.512 in	N/A 1600 kgf3520 lbf
