U-Fix Aluminum Steel 120 Degree Countersunk Head Rivets
Email This Page
Download PDF
Download PDF
Printable Page
U-Fix Aluminum Steel 120 Degree Countersunk Head Rivets
Standard Rivets
/Asset/a1196.jpg
Close Window
1 - 8 of 8
|
Results Per Page
25
50
100
200
|
View
|
Unit of Measure
Imperial
Metric
Both
1
Request Information
Compare Items
Item #
Item Name
Body Length
Minimum Grip Range
Maximum Grip Range
Nominal Shear Force
U32097K
/Asset/a1196.jpg
N/A
U-Fix 3.2 Millimeter (mm) Diameter and 9.7 Millimeter (mm) Body Length Aluminum Steel 120 Degree Countersunk Head Rivet
Body Length
N/A
9.7 mm
0.382 in
Minimum Grip Range
N/A
2.4 mm
0.094 in
Maximum Grip Range
N/A
6.4 mm
0.252 in
Nominal Shear Force
N/A
70 kgf
154 lbf
U32111K
/Asset/a1196.jpg
N/A
U-Fix 3.2 Millimeter (mm) Diameter and 11.1 Millimeter (mm) Body Length Aluminum Steel 120 Degree Countersunk Head Rivet
Body Length
N/A
11.1 mm
0.437 in
Minimum Grip Range
N/A
4.0 mm
0.157 in
Maximum Grip Range
N/A
7.9 mm
0.311 in
Nominal Shear Force
N/A
70 kgf
154 lbf
U32127K
/Asset/a1196.jpg
N/A
U-Fix 3.2 Millimeter (mm) Diameter and 12.7 Millimeter (mm) Body Length Aluminum Steel 120 Degree Countersunk Head Rivet
Body Length
N/A
12.7 mm
0.500 in
Minimum Grip Range
N/A
4.0 mm
0.157 in
Maximum Grip Range
N/A
9.5 mm
0.374 in
Nominal Shear Force
N/A
70 kgf
154 lbf
U40097K
/Asset/a1196.jpg
N/A
U-Fix 4.0 Millimeter (mm) Diameter and 9.7 Millimeter (mm) Body Length Aluminum Steel 120 Degree Countersunk Head Rivet
Body Length
N/A
9.7 mm
0.382 in
Minimum Grip Range
N/A
1.2 mm
0.047 in
Maximum Grip Range
N/A
6.4 mm
0.252 in
Nominal Shear Force
N/A
102 kgf
225 lbf
U40113K
/Asset/a1196.jpg
N/A
U-Fix 4.0 Millimeter (mm) Diameter and 11.3 Millimeter (mm) Body Length Aluminum Steel 120 Degree Countersunk Head Rivet
Body Length
N/A
11.3 mm
0.445 in
Minimum Grip Range
N/A
2.8 mm
0.110 in
Maximum Grip Range
N/A
7.9 mm
0.311 in
Nominal Shear Force
N/A
102 kgf
225 lbf
U40127K
/Asset/a1196.jpg
N/A
U-Fix 4.0 Millimeter (mm) Diameter and 12.7 Millimeter (mm) Body Length Aluminum Steel 120 Degree Countersunk Head Rivet
Body Length
N/A
12.7 mm
0.500 in
Minimum Grip Range
N/A
4.3 mm
0.169 in
Maximum Grip Range
N/A
9.5 mm
0.374 in
Nominal Shear Force
N/A
102 kgf
225 lbf
U48121K
/Asset/a1196.jpg
N/A
U-Fix 4.8 Millimeter (mm) Diameter and 12.1 Millimeter (mm) Body Length Aluminum Steel 120 Degree Countersunk Head Rivet
Body Length
N/A
12.1 mm
0.476 in
Minimum Grip Range
N/A
3.2 mm
0.126 in
Maximum Grip Range
N/A
7.9 mm
0.311 in
Nominal Shear Force
N/A
159 kgf
350 lbf
U48169K
/Asset/a1196.jpg
N/A
U-Fix 4.8 Millimeter (mm) Diameter and 16.9 Millimeter (mm) Body Length Aluminum Steel 120 Degree Countersunk Head Rivet
Body Length
N/A
16.9 mm
0.665 in
Minimum Grip Range
N/A
6.4 mm
0.252 in
Maximum Grip Range
N/A
12.7 mm
0.500 in
Nominal Shear Force
N/A
159 kgf
350 lbf
