Open End Large/X-Large Blind Rivets On Ornit USA

Catalog

1 - 25 of 31 | Results Per Page | View | Unit of Measure

1 2

Request Information Compare Items

Clear Filter

Head Diameter (mm)

Head Diameter (in)

Mandrel Diameter (mm)

Mandrel Diameter (in)

Body Length (mm)

Body Length (in)

Minimum Grip Range (mm)

Minimum Grip Range (in)

Maximum Grip Range (mm)

Maximum Grip Range (in)

Item #	Item Name	Diameter	Drill/Hole Size	Head Thickness	Head Diameter

A32080L	N/A 3.2 Millimeter (mm) Diameter and 8.0 Millimeter (mm) Body Length Open End Large Blind Rivet	N/A 3.2 mm	N/A 3.3 mm0.130 in	N/A 1.20 mm0.047 in	N/A 9.5 mm0.374 in
A32100L	N/A 3.2 Millimeter (mm) Diameter and 10.0 Millimeter (mm) Body Length Open End Large Blind Rivet	N/A 3.2 mm	N/A 3.3 mm0.130 in	N/A 1.20 mm0.047 in	N/A 9.5 mm0.374 in
A32120L	N/A 3.2 Millimeter (mm) Diameter and 12.0 Millimeter (mm) Body Length Open End Large Blind Rivet	N/A 3.2 mm	N/A 3.3 mm0.130 in	N/A 1.20 mm0.047 in	N/A 9.5 mm0.374 in
A32140L	N/A 3.2 Millimeter (mm) Diameter and 14.0 Millimeter (mm) Body Length Open End Large Blind Rivet	N/A 3.2 mm	N/A 3.3 mm0.130 in	N/A 1.20 mm0.047 in	N/A 9.5 mm0.374 in
A32160L	N/A 3.2 Millimeter (mm) Diameter and 16.0 Millimeter (mm) Body Length Open End Large Blind Rivet	N/A 3.2 mm	N/A 3.3 mm0.130 in	N/A 1.20 mm0.047 in	N/A 9.5 mm0.374 in
A40080L	N/A 4.0 Millimeter (mm) Diameter and 8.0 Millimeter (mm) Body Length Open End Large Blind Rivet	N/A 4.0 mm	N/A 4.1 mm0.161 in	N/A 1.5 mm0.059 in	N/A 12.0 mm0.472 in
A40100L	N/A 4.0 Millimeter (mm) Diameter and 10.0 Millimeter (mm) Body Length Open End Large Blind Rivet	N/A 4.0 mm	N/A 4.1 mm0.161 in	N/A 1.5 mm0.059 in	N/A 12.0 mm0.472 in
A40120L	N/A 4.0 Millimeter (mm) Diameter and 12.0 Millimeter (mm) Body Length Open End Large Blind Rivet	N/A 4.0 mm	N/A 4.1 mm0.161 in	N/A 1.5 mm0.059 in	N/A 12.0 mm0.472 in
A40140L	N/A 4.0 Millimeter (mm) Diameter and 14.0 Millimeter (mm) Body Length Open End Large Blind Rivet	N/A 4.0 mm	N/A 4.1 mm0.161 in	N/A 1.5 mm0.059 in	N/A 12.0 mm0.472 in
A40160L	N/A 4.0 Millimeter (mm) Diameter and 16.0 Millimeter (mm) Body Length Open End Large Blind Rivet	N/A 4.0 mm	N/A 4.1 mm0.161 in	N/A 1.5 mm0.059 in	N/A 12.0 mm0.472 in
A40180L	N/A 4.0 Millimeter (mm) Diameter and 18.0 Millimeter (mm) Body Length Open End Large Blind Rivet	N/A 4.0 mm	N/A 4.1 mm0.161 in	N/A 1.5 mm0.059 in	N/A 12.0 mm0.472 in
A40200L	N/A 4.0 Millimeter (mm) Diameter and 20.0 Millimeter (mm) Body Length Open End Large Blind Rivet	N/A 4.0 mm	N/A 4.1 mm0.161 in	N/A 1.5 mm0.059 in	N/A 12.0 mm0.472 in
A40220L	N/A 4.0 Millimeter (mm) Diameter and 22.0 Millimeter (mm) Body Length Open End Large Blind Rivet	N/A 4.0 mm	N/A 4.1 mm0.161 in	N/A 1.5 mm0.059 in	N/A 12.0 mm0.472 in
A48080L	N/A 4.8 Millimeter (mm) Diameter and 8.0 Millimeter (mm) Body Length Open End Large Blind Rivet	N/A 4.8 mm	N/A 4.9 mm0.193 in	N/A 1.70 mm0.067 in	N/A 14 mm0.551 in
A48100L	N/A 4.8 Millimeter (mm) Diameter and 10.0 Millimeter (mm) Body Length Open End Large Blind Rivet	N/A 4.8 mm	N/A 4.9 mm0.193 in	N/A 1.70 mm0.067 in	N/A 14 mm0.551 in
A48120L	N/A 4.8 Millimeter (mm) Diameter and 12.0 Millimeter (mm) Body Length Open End Large Blind Rivet	N/A 4.8 mm	N/A 4.9 mm0.193 in	N/A 1.70 mm0.067 in	N/A 14 mm0.551 in
A48140L	N/A 4.8 Millimeter (mm) Diameter and 14.0 Millimeter (mm) Body Length Open End Large Blind Rivet	N/A 4.8 mm	N/A 4.9 mm0.193 in	N/A 1.70 mm0.067 in	N/A 14 mm0.551 in
A48160L	N/A 4.8 Millimeter (mm) Diameter and 16.0 Millimeter (mm) Body Length Open End Large Blind Rivet	N/A 4.8 mm	N/A 4.9 mm0.193 in	N/A 1.70 mm0.067 in	N/A 14 mm0.551 in
A48180L	N/A 4.8 Millimeter (mm) Diameter and 18.0 Millimeter (mm) Body Length Open End Large Blind Rivet	N/A 4.8 mm	N/A 4.9 mm0.193 in	N/A 1.70 mm0.067 in	N/A 14 mm0.551 in
A48200L	N/A 4.8 Millimeter (mm) Diameter and 20.0 Millimeter (mm) Body Length Open End Large Blind Rivet	N/A 4.8 mm	N/A 4.9 mm0.193 in	N/A 1.70 mm0.067 in	N/A 14 mm0.551 in
A48220L	N/A 4.8 Millimeter (mm) Diameter and 22.0 Millimeter (mm) Body Length Open End Large Blind Rivet	N/A 4.8 mm	N/A 4.9 mm0.193 in	N/A 1.70 mm0.067 in	N/A 14 mm0.551 in
A48250L	N/A 4.8 Millimeter (mm) Diameter and 25.0 Millimeter (mm) Body Length Open End Large Blind Rivet	N/A 4.8 mm	N/A 4.9 mm0.193 in	N/A 1.70 mm0.067 in	N/A 14 mm0.551 in
A48300L	N/A 4.8 Millimeter (mm) Diameter and 30.0 Millimeter (mm) Body Length Open End Large Blind Rivet	N/A 4.8 mm	N/A 4.9 mm0.193 in	N/A 1.70 mm0.067 in	N/A 14 mm0.551 in
A48120X	N/A 4.8 Millimeter (mm) Diameter and 12.0 Millimeter (mm) Body Length Open End X-Large Blind Rivet	N/A 4.8 mm	N/A 4.9 mm0.193 in	N/A 1.80 mm0.071 in	N/A 15.8 mm0.622 in
A48140X	N/A 4.8 Millimeter (mm) Diameter and 14.0 Millimeter (mm) Body Length Open End X-Large Blind Rivet	N/A 4.8 mm	N/A 4.9 mm0.193 in	N/A 1.80 mm0.071 in	N/A 15.8 mm0.622 in
