P-Series Open End Countersunk Head (CSK) Rivet Nuts On Ornit USA

Catalog

1 - 25 of 38 | Results Per Page | View | Unit of Measure

1 2

Request Information Compare Items

Clear Filter

Thread Size

Minimum Grip Range (mm)

Maximum Grip Range (mm)

Hole Size (mm)

Item #	Item Name	Thread Size	Dimension L	Minimum Grip Range	Maximum Grip Range

ORMC-03090-POP	N/A P-Series 9.0 Millimeter (mm) Dimension L and M3 Thread Size Open End Countersunk Head (CSK) Rivet Nut	N/A M3	N/A 9.0 mm	N/A 0.5 mm	N/A 1.5 mm
ORMC-03100-POP	N/A P-Series 10.0 Millimeter (mm) Dimension L and M3 Thread Size Open End Countersunk Head (CSK) Rivet Nut	N/A M3	N/A 10 mm	N/A 1.5 mm	N/A 2.5 mm
ORMC-04105-POP	N/A P-Series 10.5 Millimeter (mm) Dimension L and M4 Thread Size Open End Countersunk Head (CSK) Rivet Nut	N/A M4	N/A 10.5 mm	N/A 0.5 mm	N/A 1.5 mm
ORMC-04115-POP	N/A P-Series 11.5 Millimeter (mm) Dimension L and M4 Thread Size Open End Countersunk Head (CSK) Rivet Nut	N/A M4	N/A 11.5 mm	N/A 1.5 mm	N/A 2.5 mm
ORMC-04125-POP	N/A P-Series 12.5 Millimeter (mm) Dimension L and M4 Thread Size Open End Countersunk Head (CSK) Rivet Nut	N/A M4	N/A 12.5 mm	N/A 2.5 mm	N/A 3.5 mm
ORMC-05110-POP	N/A P-Series 11.0 Millimeter (mm) Dimension L and M5 Thread Size Open End Countersunk Head (CSK) Rivet Nut	N/A M5	N/A 11.0 mm	N/A 0.5 mm	N/A 1.5 mm
ORMC-05120-POP	N/A P-Series 12.0 Millimeter (mm) Dimension L and M5 Thread Size Open End Countersunk Head (CSK) Rivet Nut	N/A M5	N/A 12.0 mm	N/A 1.5 mm	N/A 2.5 mm
ORMC-05130-POP	N/A P-Series 13.0 Millimeter (mm) Dimension L and M5 Thread Size Open End Countersunk Head (CSK) Rivet Nut	N/A M5	N/A 13.0 mm	N/A 2.5 mm	N/A 3.5 mm
ORMC-06140-POP	N/A P-Series 14.0 Millimeter (mm) Dimension L and M6 Thread Size Open End Countersunk Head (CSK) Rivet Nut	N/A M6	N/A 14.0 mm	N/A 0.5 mm	N/A 2.5 mm
ORMC-06155-POP	N/A P-Series 15.5 Millimeter (mm) Dimension L and M6 Thread Size Open End Countersunk Head (CSK) Rivet Nut	N/A M6	N/A 15.5 mm	N/A 2.5 mm	N/A 3.5 mm
ORMC-08155-POP	N/A P-Series 15.5 Millimeter (mm) Dimension L and M8 Thread Size Open End Countersunk Head (CSK) Rivet Nut	N/A M8	N/A 15.5 mm	N/A 1.0 mm	N/A 2.5 mm
ORMC-08170-POP	N/A P-Series 17.0 Millimeter (mm) Dimension L and M8 Thread Size Open End Countersunk Head (CSK) Rivet Nut	N/A M8	N/A 17.0 mm	N/A 2.5 mm	N/A 4.0 mm
ORMC-10165-POP	N/A P-Series 16.5 Millimeter (mm) Dimension L and M10 Thread Size Open End Countersunk Head (CSK) Rivet Nut	N/A M10	N/A 16.5 mm	N/A 1.0 mm	N/A 2.5 mm
ORMC-10180-POP	N/A P-Series 18.0 Millimeter (mm) Dimension L and M10 Thread Size Open End Countersunk Head (CSK) Rivet Nut	N/A M10	N/A 18 mm	N/A 2.5 mm	N/A 4.0 mm
ORMC-03100-POR	N/A P-Series 10.0 Millimeter (mm) Dimension L and M3 Thread Size Open End Countersunk Head (CSK) Rivet Nut	N/A M3	N/A 10 mm	N/A 1.5 mm	N/A 2.5 mm
ORMC-04105-POR	N/A P-Series 10.5 Millimeter (mm) Dimension L and M4 Thread Size Open End Countersunk Head (CSK) Rivet Nut	N/A M4	N/A 10.5 mm	N/A 0.5 mm	N/A 1.5 mm
ORMC-04115-POR	N/A P-Series 11.5 Millimeter (mm) Dimension L and M4 Thread Size Open End Countersunk Head (CSK) Rivet Nut	N/A M4	N/A 11.5 mm	N/A 1.5 mm	N/A 2.5 mm
ORMC-04125-POR	N/A P-Series 12.5 Millimeter (mm) Dimension L and M4 Thread Size Open End Countersunk Head (CSK) Rivet Nut	N/A M4	N/A 12.5 mm	N/A 2.5 mm	N/A 3.5 mm
ORMC-05110-POR	N/A P-Series 11.0 Millimeter (mm) Dimension L and M5 Thread Size Open End Countersunk Head (CSK) Rivet Nut	N/A M5	N/A 11.0 mm	N/A 0.5 mm	N/A 1.5 mm
ORMC-05120-POR	N/A P-Series 12.0 Millimeter (mm) Dimension L and M5 Thread Size Open End Countersunk Head (CSK) Rivet Nut	N/A M5	N/A 12.0 mm	N/A 1.5 mm	N/A 2.5 mm
ORMC-05130-POR	N/A P-Series 13.0 Millimeter (mm) Dimension L and M5 Thread Size Open End Countersunk Head (CSK) Rivet Nut	N/A M5	N/A 13.0 mm	N/A 2.5 mm	N/A 3.5 mm
ORMC-06140-POR	N/A P-Series 14.0 Millimeter (mm) Dimension L and M6 Thread Size Open End Countersunk Head (CSK) Rivet Nut	N/A M6	N/A 14.0 mm	N/A 0.5 mm	N/A 2.5 mm
ORMC-06155-POR	N/A P-Series 15.5 Millimeter (mm) Dimension L and M6 Thread Size Open End Countersunk Head (CSK) Rivet Nut	N/A M6	N/A 15.5 mm	N/A 2.5 mm	N/A 4.0 mm
ORMC-08155-POR	N/A P-Series 15.5 Millimeter (mm) Dimension L and M8 Thread Size Open End Countersunk Head (CSK) Rivet Nut	N/A M8	N/A 15.5 mm	N/A 1.0 mm	N/A 2.5 mm
ORMC-08170-POR	N/A P-Series 17.0 Millimeter (mm) Dimension L and M8 Thread Size Open End Countersunk Head (CSK) Rivet Nut	N/A M8	N/A 17.0 mm	N/A 2.5 mm	N/A 4.0 mm
