Interior - Seats
The Orlock™ fastener is a structural rivet and features a double-locking system that enables the rivet to safely secure the seats.

Side Frame
The Orlock™ fastener is an excellent choice for your trailer frame. The Orlock™ is designed to support exceptionally high shear and tensile forces. Its retained stem provides a strong, vibration-resistant joint.

Front Frame
The Orlock™ structural rivet provides great shear and tensile forces to create a highly secure double locking system, vibration-resistance joint. It is the ideal alternative to nuts, bolts and screws.

Hinges, Axis, Locking System
The Orlock™ fastener, with its double-locking system, provides high shear and tensile forces to create a highly secure, vibration-resistance joint. It is the ideal alternative to nuts, bolts and screws.
Unit of Measure

Technical Specs

Brands

 N/A Orlock™ Ornit

Carton Quantity

 N/A 1000

Body Material

 N/A Low Carbon Steel

Body Finish

 N/A Zinc Plated Chromium (Cr) VI Free Passivation

Mandrel Material

 N/A Carbon Steel

Mandrel Finish

 N/A Zinc Plated Chromium (Cr) VI Free Passivation

Head Style

 N/A Countersunk

Nominal Dimensions

Diameter

 N/A 7.8 mm5/16 in

Drill/Hole Size

 N/A 8.0 to 8.3 mm0.315 to 0.327 in

Head Thickness

 N/A 3.40 mm0.134 in

Head Diameter

 N/A 14.5 mm0.571 in

Mandrel Diameter

 N/A 5.12 mm0.202 in

Body Length

 N/A 20.5 mm0.807 in

Minimum Grip Range

 N/A 10.0 mm0.394 in

Maximum Grip Range

 N/A 13.0 mm0.512 in

Nominal Forces

Nominal Shear Force

 N/A 1400 kgf3087 lbf

Nominal Tensile Force

 N/A 750 kgf1654 lbf

Applications

Rail Transport Application

 N/A Trains
This extra-large diameter, Orlock, structural rivet provides the perfect solution for train assembly lines. The rivet provides a highly secure, vibration-resistance joint and is the ideal alternative to nuts, bolts and screws.
