Unit of Measure

Technical Specs

Brands

 N/A Ornit

Carton Quantity

 N/A 7000

Body Material

 N/A Aluminum Alloy ALmg 2.5

Body Finish

 N/A Natural

Mandrel Material

 N/A Low Carbon Steel

Mandrel Finish

 N/A Zinc Plated Chromium (Cr) VI Free

Head Style

 N/A Large Head

Nominal Dimensions

Diameter

 N/A 3.2 mm1/8 in

Drill/Hole Size

 N/A 3.3 mm0.130 in

Head Thickness

 N/A 1.0 mm0.039 in

Head Diameter

 N/A 8.25 mm0.325 in

Mandrel Diameter

 N/A 1.81 mm0.071 in

Body Length

 N/A 12.7 mm0.500 in

Minimum Grip Range

 N/A 5.5 mm0.217 in

Maximum Grip Range

 N/A 9.5 mm0.374 in

Nominal Forces

Nominal Shear Force

 N/A 75 kgf165 lbf

Nominal Tensile Force

 N/A 104 kgf230 lbf
