Brands |
N/A Ornit Super Orlock™ |
Carton Quantity |
N/A 2000 |
Body Material |
N/A Low Carbon Steel |
Body Finish |
N/A Zinc Coated Chromium (Cr) VI Free |
Mandrel Material |
N/A Austenitic Stainless Steel American Iron and Steel Institute (AISI) 304 |
Mandrel Finish |
N/A Natural |
Head Style |
N/A Protruding |
Diameter |
N/A 6.5 mm1/4 in |
Drill/Hole Size |
N/A 6.7 to 6.9 mm0.263 to 0.271 in |
Head Thickness |
N/A 3.0 mm0.118 in |
Head Diameter |
N/A 13.0 mm0.512 in |
Mandrel Diameter |
N/A 4.17 mm0.164 in |
Body Length |
N/A 18.5 mm0.728 in |
Minimum Grip Range |
N/A 9.0 mm0.354 in |
Maximum Grip Range |
N/A 12.5 mm0.492 in |
Rail Transport Application |
N/A
Cable Car When extra forces are required, the Super Orlock™ is the solution. The Super Orlock™ provides higher shear and tensile strengths, a wider grip range and creates an extremely secure, vibration–resistant joint. The stainless steel version is also commonly used for this type of application. Trains When extra forces are required, the Super Orlock™ is the solution. The Super Orlock™ provides higher shear and tensile strengths, a wider grip range and creates an exceptionally secure, vibration–resistant joint. The stainless steel version is also available in a variety of grades. |
Renewable Energy Application |
N/A
Solar Frames The Orlock™ Stainless Steel is commonly used in a variety of solar applications worldwide. This stainless steel rivet provides a permanent, secure joint in the most severe climate conditions. Also available in 316. |
