Side Frame
Structural rivet with high strength that comes with Double locking system. Always flush break and Vibration resistance. has a Wide grip range.

Front Frame
Structural rivet with high strength comes with Double locking system. Always flush break and Vibration resistance. has a Wide grip range.
Unit of Measure

Technical Specs

Brands

 N/A Nitlock Ornit

Carton Quantity

 N/A 2000

Body Material

 N/A Carbon Steel

Body Finish

 N/A Zinc Plated Chromium (Cr) VI Free Passivation

Mandrel Material

 N/A Carbon Steel

Mandrel Finish

 N/A Zinc Plated Chromium (Cr) VI Free Passivation

Head Style

 N/A Protruding

Nominal Dimensions

Diameter

 N/A 6.4 mm1/4 in

Drill/Hole Size

 N/A 6.63 to 6.90 mm0.261 to 0.272 in

Head Thickness

 N/A 3.0 mm0.118 in

Head Diameter

 N/A 13.0 mm0.512 in

Mandrel Diameter

 N/A 4.10 mm0.161 in

Body Length

 N/A 14.2 mm0.559 in

Minimum Grip Range

 N/A 2.5 mm0.098 in

Maximum Grip Range

 N/A 9.5 mm0.374 in

Nominal Forces

Nominal Shear Force

 N/A 1590 kgf3500 lbf

Nominal Tensile Force

 N/A 865 kgf1907 lbf

Applications

Renewable Energy Application

 N/A Solar Frame
Structural rivet with high strength comes with Double locking system. Always flush break and Vibration resistance. has a Wide grip range.
