Interior Main Cabin
The U-Fix fastener is a highly versatile, purpose-built fastener, featuring an excellent multi-grip function ideal for a variety of applications within the main cabin.

Side Frame
The U-Fix is a highly versatile, purpose made fastener, featuring an excellent multigrip function suitable for a variety of trailer applications when additional accessories are needed.

Securing Rails
The U-Fix is a highly versatile, purpose-built fastener, featuring an excellent multi-grip function suited to a variety of purposes. Recommended for securing rails within the trailer.
Unit of Measure

Technical Specs

Brands

 N/A Ornit

Diameter

 N/A 4.8 mm3/16 in

Drill/Hole Size

 N/A 4.9 mm0.193 in

Head Thickness

 N/A 1.45 mm0.057 in

Head Diameter

 N/A 9.8 mm0.386 in

Mandrel Diameter

 N/A 2.9 mm0.114 in

Body Length

 N/A 17.0 mm0.669 in

Minimum Grip Range

 N/A 5.5 mm0.216 in

Maximum Grip Range

 N/A 12.0 mm0.472 in

Nominal Shear Force

 N/A 450 kgf990 lbf

Nominal Tensile Force

 N/A 390 kgf858 lbf

Carton Quantity

 N/A 4000

Body Material

 N/A Low Carbon Steel

Body Finish

 N/A Zinc Plated Chromium (Cr) VI Free

Mandrel Material

 N/A Carbon Steel

Mandrel Finish

 N/A Zinc Plated Chromium (Cr) VI Free

Head Style

 N/A Dome

Applications

Automotive Application

 N/A Interior
The U-Fix is a highly versatile purpose-built fastener, featuring an excellent multi-grip function ideal for a variety of purposes. Commonly used to secure components within the vehicle.
