Unit of Measure

Technical Specs

Brands

 N/A Ornit

Carton Quantity

 N/A 7000

Head Style

 N/A Steel Dome

Body Material

 N/A Low Carbon Steel, SAE 1006 or Equivalent

Body Finish

 N/A Natural

Mandrel Material

 N/A Low Carbon Steel SAE 1006-1022

Mandrel Finish

 N/A Zinc Plated Chromium (Cr) VI Free

Nominal Dimensions

Diameter

 N/A 4.0 mm

Drill/Hole Size

 N/A 4.1 mm0.161 in

Head Thickness

 N/A 1.15 mm0.045 in

Head Diameter

 N/A 7.8 mm0.307 in

Mandrel Diameter

 N/A 2.31 mm0.091 in

Body Length

 N/A 10.0 mm0.394 in

Minimum Grip Range

 N/A 3.5 mm0.138 in

Maximum Grip Range

 N/A 5.5 mm0.217 in

Nominal Forces

Nominal Shear Force

 N/A 190 kgf418 lbf

Nominal Tensile Force

 N/A 280 kgf616 lbf
